Series Trucks - Gearbox & Propshaft

Page 1
  Engine <> Flywheel & Clutch <> Gearbox & Propshaft <> Axles Suspension and Steering <> Brakes & Brake Controls <> Fuel, Exhaust, Emmission Systems <> Cooling & Heating <> Electrical, Washers-Wipers, Instruments <> Chassis, Subframes, Bodyshell, Fittings <> Facia, Trim, Seats and Fixings <> Screws, Nuts, Bolts

  Series - Gearbox & Propshaft - Page 1 <> Page 2 <> Page 3




  Engine / Transmission Mount - Rear
  Ref: NRC2053 / Price $4.99
  Application: Series 2.25 and 2.6 - uses M10 nuts


  Selector Fork Reverse


Ref: 576704 / Price $84.95


  Application: Series III, Suffix 'A'


  Selector Fork Reverse
  Ref: FRC1815 / Price $39.95
  Application: Series III, Suffix 'B' onwards


  Selector Fork 1st and 2nd SIII - NLA
  Ref: 576703 / Price $125.00


Application: Series III




  Detent Spring Selector Shafts
  Ref: 3649 / Price $0.75
  Application: Series (all)


  Detent Spring - Reverse Selector Shaft
  Ref: 56102 / Price $2.59
  Application: Series


  Seal - Detent Spring
  Ref: 5852 / Price $0.75
  Application: Series (all)


  Selector Shaft Block
  Ref: 233406 / Price $5.95
  Application: Series IIa and III


  Main Casing Dowel
  Ref: 7289 / Price $2.95
  Application: Series IIa and III - 2 required


  Oil Seal - Primary Pinion - 'CORTECO'
  Ref: 571059G / Price $5.99
  Application: Series III & Stage One V8


  Oil Seal - Primary Pinion - 'ALLMAKES'
  Ref: 571059 / Price $3.99
  Application: Series III & Stage One V8




Circlip - Primary Pinion


  Ref: 214795 / Price $1.25
  Application: Series III


  Bearing for Primary Pinion
  Ref 55714 / Price $26.74
  Bearing 1st Motion Series 2 + 3


  3rd and 4th Syncro Clutch
  Ref: FRC1758 / Price $124.95
  Application: Series (all) 1948 - 1981


  Syncro Clutch Spring
  Ref: RTC1956 / Price $1.25
  Application: Series (all)


  Block for In/Out Syncro OE
  Ref: 553084 / Price $0.99
  Application: Series III


  Spring
  Ref: 503805 / Price $0.99
  Application: Series III In/Out Syncro


  Ball for In/Out Syncro - Genuine
  Ref: BLS108L / $1.38
  Application: Series III In/Out Syncro


  Washer
  Ref: 576907 / Price $2.95
  Application: Series Gearbox Layshaft


  Split Ring / Layshaft Gear
  Ref: 239272 / Price $4.99
  Application: Series 1948 to series IIa - non synchro box


  Locker - Layshaft
  Ref: 528683 / Price $1.49
  Application: Series (all) - genuine


  Retaining Plate
  Ref: 528690 / Price $14.95
  Application: Series III


  Bearing Lay Shaft Series 1 & 2
  Ref: 576207 / $21.95
  Application: Early Front Lay Shaft Bearing Ser 1 & 2
Description: Outer diameter 1 7/8" inner 3/4" Superceded from 09962


  Bearing Lay Shaft Series 2a & 3
  Ref: 528701 / $11.75
  Application: Front Lay Shaft Bearing Ser 2a & 3
Description: Outer diameter 2 3/8" inner 1 1/16" Series III Suffix 'A' and 'B' onwards


  Distance Piece
  Ref: 528720 / Price $3.95
  Application: Gearbox Suff A and B onwards - Front layshaft end float conical distance piece, 0.405"


  Distance Piece 'OEM'
  Ref: 528721 / Price $4.95
  Application: Gearbox Suff A and B onwards - Front layshaft end float conical distance piece, 0.425"


  Distance Piece 'OEM'
  Ref: 528722 / Price $4.95
  Application: Gearbox Suff A and B onwards - Front layshaft end float conical distance piece, 0.445"


  Main Drive Gear and Constant Gear Set
  Ref: 606880 / Price $199.00
  Application: Series III up to suffix 'C' inclusive


  Layshaft
  Ref: 556040 / Price $134.95
  Application: Series II and IIa - Suffix D onwards


  Layshaft Cluster A
  Ref: 576686 / Price $149.95
  Application: Series III suffix A


  Bearing - Lay Shaft - Rear
  Ref: RTC1412 / Price $29.95
  Application: Rear Lay Shaft Bearing Ser 2& 3
Description: Series II and IIa and Series III Suffix 'A' and 'B' onwards


  1st Gear - Layshaft
  Ref: 501616 / Price $38.95
  Application: Series II and IIa suffix A and B - superceded from 217388


  1st Gear - Layshaft
  Ref: 511189 / Price $28.95
  Application: Series suffix C onwards


  High Gear Wheel
  Ref: 218243 / Price $56.95
  Application Series (all)


  Reverse Gear Cluster
  Ref: 90217389 / Price $105.95


Application: Series IIa - Suffix A and B





  Reverse Idler Gear SIII - Suffix 'A'
  Ref: 576707 / Price $44.84
  Application: Series III - Suffix 'A'


  Reverse Idler Shaft
  Ref: 591527 / Price $14.95
  Application: Series Suffix A Box


  Reverse Idler Gear SIII - Suffix B onwards
  Ref: FRC1810 / Price $55.60
  Application: Series III Suffix B onwards


  Reverse Idler Shaft
  Ref: FRC1813 / Price $14.95
  Application: Series Suffix 'B' Onwards


  Spring Pin - Reverse Idler Shaft
  Ref: 591519 / Price $0.25
  Application: Series Suff A and B Onwards


  Mainshaft - SII and IIa - NLA
  Ref: 264250 / Price $139.84
  Application: Series II and IIa


  Mainshaft - SIII
  Ref: 576725 / Price $109.95
  Application: Series III


  Bearing - Mainshaft Front
  Ref: 6397 / Price $8.95
  Application: Series II and III


  Snap Ring - Mainshaft Front
  Ref: RTC1957 / Price $1.83


Application: Series (all) supercedes from 6402 - Genuine Land Rover



  Thrust Washer 3rd Gear 0.125
  Ref: RTC1962 / Price $7.95
  Application: Series II and IIa and III


  Thrust Washer 3rd Gear 0.130
  Ref: 50703 / Price $7.95
  Application: Series II and IIa and III


  3RD Mainshaft Gear SIII
  Ref: 556010 / Price $87.90
  Application: Series III up to Suffix 'C' inclusive


  Bush 2nd and 3rd Gear - Early
  Ref: 571218 / Price $18.95
  Application: Series II and III


  Bush - 3rd Gear Series III
  Ref: FRC4077 / Price $8.95
  Application: Series III


  Mainshaft Bush - Series III
  Ref: FRC4076 / Price $10.95
  Application: Bush for Second Gear Series III


  2nd Gear Pair (Early)
  Ref: 245766 / Price $74.95
  Application: Series II and IIa - Suffix A - C


  Gear - 2nd Speed - Mainshaft
  Ref: 591363 / Price $89.95
  Application: Series III up to suffix D


  Gear - 2nd Speed - Mainshaft
  Ref: FRC2673 / Price $94.95
  Application: Series III Suffix D


  Thrust Washer 2nd Gear - 0.125"
  Ref: 267572 / Price $9.95
  Application: Series II, IIa and III


  Thrust Washer 2nd Gear - 0.128"
  Ref: 267573 / Price $9.95
  Application: Series II, IIa and III


  Thrust Washer 2nd Gear - 0.130"
  Ref: 267574 / Price $9.95
  Application: Series II, IIa and III


  Thrust Washer 2nd Gear - 0.135"
  Ref: 267575 / Price $9.95
  Application: Series II, IIa and III


  Syncromesh Ring - 1st and 2nd Gear
  Ref: 591364 / Price $10.99
  Application: Series III


  Peg for Mainshaft
  Ref: 6405 / Price $0.75
  Application: Series (all)


  Peg for Mainshaft
  Ref: RTC1979 / Price $0.75
  Application: Series (all) supercedes from 9561


  In & Out Member SIII Suff 'A'
  Ref: 608283 / Price $148.95
  Application: Series III, Suffix 'A'


  In & Out Member SIII Suff 'B and C'
  Ref: RTC2195 / Price $89.00
  Application: Series III, Suffix 'B" and 'C' inclusive


  In & Out Member SIII Suff 'D'
  Ref: RTC2685 / Price $179.00
  Application: Series III, Suffix 'D'


  1st Gear SIIA Suff C
  Ref: 511205 / Price $79.38
  Application: Series IIa Suffix C - 30 Teeth


  1st Gear SIII Suff A & B
  Ref: 591362 / Price $66.32
  Application: Series III Suffix A & B inclusive - 35 teeth


  Gear - Ist Speed - Mainshaft SIII
  Ref: FRC2056 / Price $72.95
  Application: Series III, Gearbox suffix 'C' - 31 teeth


  Gear - Ist Speed - Mainshaft SIII
  Ref: FRC3201 / Price $128.95
  Application: Series III, Gearbox suffix D onwards - 31 teeth


  Bush for 1st Mainhsaft Gear SIII OE
  Ref: 576734 / Price $19.99
  Application: Series III


  Thrust Washer - Genuine
  Ref: 576735 / Price $29.95
  Application: Series III - Mainshaft Rear


  Bearing - Mainshaft Center


Ref: 1645 / Price $18.95




Application: Series (all)



  Housing - Mainshaft Bearing - Brtipart
  Ref: FRC5115 / Price $66.95
  Application: Series (all) except V8


  Circlip
  Ref: 9960 / Price $1.45
  Application: Series III Gearbox


  Oil Seal - Allmakes
  Ref: 236305 / Price $4.59
  Application: Series (all) Oil seal rear of main shaft, seal between gearbox and transfer case


  Oil Thrower
  Ref: FRC5116 / Price $2.49
  Application: Series III - Use with transfer case FRC5567 - Suff C and D


  Rear Spacer - Mainshaft
  Ref: 502482 / Price $15.95
  Application: Series excluding 1 Ton


  Gear - Rear Mainshaft
  Ref: 218244 / Price $118.45
  Application: Series (all) Note: If you have an overdrive unit then this is the gear plus your rear mainshaft housing that you should have in your spares box , believe me I know. Happened to me at 1 am at 20 below zero, not fun!


  Shim
  Ref: 501501 / Price $0.59
  Application: Series - Shim/Washer for mainshaft nut and lock washer


  Lock Washer - Rear Mainshaft - Genuine
  Ref: 217476 / Price $0.49
  Application: Series (all) excl 1 ton


  Mainshaft Nut
  Ref: 217477 / Price $3.50


Application: Series (all)



  Bellhousing Seal - NLA
  Ref: 236281
  Application: Series II and IIa Bellhousing Grommet Suffix A - D


  Bellhousing Grommet
  Ref: 553262 / Price $19.95
  Application: Series IIa Bellhousing Grommet Suffix E onwards


  Grommet
  Ref: 345140 / Price $3.75
  Application: 2.6L Tunnel - Diameter of round hole approx 50mm


  Grommet
  Ref: 232604 / Price $28.95
  Application: Plug for bell housing Suffix A. Approx 3" X 2.5" - spherical


  Grommet
  Ref: 334189 / Price $11.99
  Application: Series (all) grommet for gearbox tunnel - round
